Nylon Cable Clamps

PRODUCT NAME:
Nylon Cable Clamps
PRODUCT MODEL:
CONTACT US:
Tel : +008613356192265
TEL : +0086057762711310
E-mail : sales@txele.cc
Skype : chinacuze
INQUIRY

Product Specifications

● Material: UL approved Nylon 66, 94V-2
● Color: Natural, available in other colors.
● CABLE CLAMPS are designed to hold cables, tubes and components in domestic appliance, electronics and electric apparatus generally.
● Interior edges are rounded to protect cable insulation.
● To apply, just clamp down on loosen cables and screw it to chassis.

Item No A B C D E
UC-3.3 1/8" 9.5 9.6 3.3 17 4.0
UC-5.2 3/16" 10.5 9.6 5.5 18.5 4.0
UC-6.4 1/4" 12 9.6 6.35 21 4.0
UC-8.4 5/16" 12.5 9.6 8.35 22.8 4.0
UC-10.4 3/8" 13.5 9.6 10.35 23.8 4.0
UC-13.2 1/2" 13.5 9.6 12.7 25.8 4.0
UC-16 5/8" 16.5 9.6 15.8 30.5 4.0
UC-19 3/4" 17 12 19 35.5 4.0
UC-23 1" 26 13 23 44 4.0
UC-30 11/16" 23 12.7 30 47 4.0
UC-50 11/2" 41 12.5 50 77 4.0
